Beginner

Docker - Traefik Advanced

Linux

Intro

After a Basic Setup with fix Configuration, here an example where we put some Variables in a “.env” File.

Requirements:

Linux Host with Docker see here, Public IP Adress and rechable Port 80 & 443

two FQDN pointing to your IP:

  • traefik.yourdomain.de
  • whoami.yourdomain.de

Env Vars

let’s run the following Commands which generates a “.env” File. It will also create a User “dashboard” and ask you twice for the Password

echo 'domain="your.domain.de"'      > .env
echo 'traefik="traefik.${domain}"'  >> .env
echo 'whoami="whoami.${domain}"'    >> .env
echo 'mail="name@${domain}"'        >> .env
echo -n 'dashboardaccount="' >> .env; echo -n $(htpasswd -nB dashboard) |sed -e s/\\$/\\$\\$/g >> .env; echo '"' >> .env

.env

and here is the Content of my .env File.

Dotnet - Hello World

Code

Running a WebApp in 5min ?

ASP.NET Tutorial - Hello World in 5 minutes

in a Language you never touched before … ? a Microsoft App running on Linux running in Docker running on macOS … ?

Let’ give a try …

Fireup Ubuntu via Docker, do Port Forward

docker run -it -p 5123:5123 --name dotnet-hello ubuntu:latest

add basics

apt-get update && apt-get -y upgrade && apt-get -y install wget

add dotnet

wget https://packages.microsoft.com/config/ubuntu/22.10/packages-microsoft-prod.deb -O packages-microsoft-prod.deb
dpkg -i packages-microsoft-prod.deb && rm packages-microsoft-prod.deb
apt-get update && apt-get install -y dotnet-sdk-7.0
dotnet --version

build webapp

dotnet new webapp -o MyWebApp --no-https -f net7.0

run webapp, change IP & Port

cd MyWebApp
sed -i 's#"applicationUrl".*#"applicationUrl": "http://0.0.0.0:5123",#' Properties/launchSettings.json
dotnet watch

Hello World

Docker - Traefik

Linux

Intro

Following a Working Example how to get Traefik and a few Dummy Containers running on Docker. If you wanna have a bit advanced Example and put some Variables in a “.env” File, you may wanna check this Post.

Requirements

Linux Host with Docker see here, Public IP Adress and rechable Port 80 & 443

two FQDN pointing to your IP:

  • traefik.yourdomain.de
  • whoami.yourdomain.de

Docker Traefik Example

cat << EOF > docker-compose.yml
version: "3.3"

services:
  traefik:
    image: "traefik:v2.9"
    container_name: "traefik"
    command:
      # Traefik Log
      - "--log.level=DEBUG"
      - "--log.filePath=/logs/traefik.log"
      - "--api.insecure=true"
      - "--api.dashboard=true"
      - "--providers.docker=true"
      - "--providers.docker.exposedbydefault=false"
      - "--entrypoints.web.address=:80"
      # Access Log
      - "--accesslog=true"
      - "--accesslog.filePath=/logs/access.log"
      # Prometheus metrics
      ## Enable prometheus metrics
      - "--metrics.prometheus=true"
      ## Create a manual router instead of the default one.
      - "--metrics.prometheus.manualrouting=true"
      - "--metrics.prometheus.addrouterslabels=true"
    ports:
      - "80:80"
    volumes:
      - "/var/run/docker.sock:/var/run/docker.sock:ro"
      - "./logs/:/logs/"
    labels:
      - "traefik.enable=true"
      - "traefik.http.routers.dashboard.rule=Host(`traefik.yourdomain.de`)"
      - "traefik.http.routers.dashboard.entrypoints=web"
      - "traefik.http.routers.dashboard.service=api@internal"
      # Auth: dasboard/XXXXXXXX
      - "traefik.http.routers.dashboard.middlewares=dashboard_auth"
      - "traefik.http.middlewares.dashboard_auth.basicauth.users=dashboard:$$XXXXXXXXXXXXXXXXXXXX"

  whoami:
    image: "traefik/whoami"
    container_name: "simple-service"
    labels:
      - "traefik.enable=true"
      - "traefik.http.routers.whoami.rule=Host(`whoami.yourdomain.de`)"
      - "traefik.http.routers.whoami.entrypoints=web"
EOF

Up

docker compose up -d

Redirect HTTP to HTTPS

replace [email protected], traefik.yourdomain.de and whoami.yourdomain.de with the appropriate Values …

Docker on Debian

Docker

Let’s Setup Docker on Debian

Get Debian on some Cloud Provider

Update Apt

apt-get install ca-certificates curl gnupg lsb-release

add official GPG Keys

mkdir -p /etc/apt/keyrings
curl -fsSL https://download.docker.com/linux/debian/gpg |gpg --dearmor -o /etc/apt/keyrings/docker.gpg

add Repo to Sources

echo \
  "deb [arch=$(dpkg --print-architecture) signed-by=/etc/apt/keyrings/docker.gpg] https://download.docker.com/linux/debian \
  $(lsb_release -cs) stable" |tee /etc/apt/sources.list.d/docker.list > /dev/null

install Docker Engine

apt-get update
apt-get install docker-ce docker-ce-cli containerd.io docker-compose-plugin

Check Version

docker version

root@docker:~# docker version
Client: Docker Engine - Community
 Version:           20.10.18
 API version:       1.41
 Go version:        go1.18.6
 Git commit:        b40c2f6
 Built:             Thu Sep  8 23:12:08 2022
 OS/Arch:           linux/amd64
 Context:           default
 Experimental:      true

Docker Compose Version

docker compose version

root@docker:~# docker compose version
Docker Compose version v2.10.2

Install Hello World

docker run hello-world

Prepare Folders

mkdir -p /etc/docker/container/traefik
cd /etc/docker/container/traefik

Build Docker-compose

cat << 'EOF' > docker-compose.yml
services:
  traefik:
    image: traefik:v2.6
    restart: always
    command:
      - "--providers.docker"
      - "--providers.docker.exposedByDefault=false"
      - "--providers.docker.network=traefik_web"
      - "--entrypoints.http.address=:80"
      - "--entrypoints.http.http.redirections.entrypoint.to=https"
      - "--entrypoints.http.http.redirections.entrypoint.scheme=https"
      - "--entrypoints.https.address=:443"
      - "--entrypoints.https.http.tls.certResolver=le"
      - "--certificatesresolvers.le.acme.tlschallenge=true"
      - "[email protected]"
      - "--certificatesresolvers.le.acme.storage=/letsencrypt/acme.json"
    ports:
      - "80:80"
      - "443:443"
      - "8080:8080"
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock:ro
      - ./letsencrypt:/letsencrypt
networks:
  web:
    name: traefik_web
EOF

docker compose up

docker compose up -d

docker compose ps

docker compose ps

NAME                COMMAND                  SERVICE             STATUS              PORTS
traefik-traefik-1   "/entrypoint.sh --pr…"   traefik             running             0.0.0.0:80->80/tcp, :::80->80/tcp, 0.0.0.0:443->443/tcp, :::443->443/tcp, 0.0.0.0:8080->8080/tcp, :::8080->8080/tcp

Demo Nginx

mkdir -p /etc/docker/container/nginx-demo
cd /etc/docker/container/nginx-demo

docker-compose.yml

cat << 'EOF' > docker-compose.yml
services:
  nginx:
    image: nginx:1.20
    labels:
      - "traefik.enable=true"
      - "traefik.http.routers.nginx.rule=Host(`nginx.v4.docker.noflow.ch`)"
    networks:
      - traefik_web

networks:
  traefik_web:
    external: true
EOF

Nginx up

docker compose up -d

Tail logfile

docker compose logs -f

-> https://nginx.v4.docker.noflow.ch
